OFS Series Oil Free Rotary Screw Air Compressors

CLASS 0 OIL FREE AIR PLUS ROTARY SCREW DEPENDABILITY

When air purity is critical – oil free air is essential. The Sullair OFS Series of air compressors utilizes proprietary rotary screw technology in providing 100% Class 0 oil free air.

Unlike oil-flooded rotary screw compressors, Sullair OFS Series compressors introduce no oil into the compression stage. While maintaining the Sullair reputation for durable air ends, Sullair OFS Series compressors add specific elements to ensure 100% oil free operation.

  • Legendary Sullair Dry Screw Two-Stage Air End
  • Sullair WS Controller
  • Maximum Energy Efficiency and Operating Consistency

Models vary by region. Please contact your Sullair sales representative for more details.

Jump To:

Specs Contact Us
OFS
CFM
CFM

Flow

446 – 1654 cfm
12.6 - 46.8 m³/min
Pressure
Pressure

Pressure

100 – 150 psi
7 - 10 bar
Horsepower
Horsepower

Power

100 – 350 hp
75 – 261 kw

SULLAIR CONTROLLER

  • Sullair WS I/O
  • Multiline digital screen with contextual multicolor backlight
  • Multiple communications protocols
  • Built-in sequencing capability

MAIN MOTOR

  • WEG W22 series motors
  • NEMA premium efficient
  • TEFC Standard (IP55)
  • 50˚ C temperature capability

SULLAIR AIR END

  • Legendary Sullair rotary screw technology with proven two-stage efficiency
  • Ultra-long bearing life
  • Robust AGMA 12 class gears
  • Food-grade PTFE coating on elements

COOLERS

  • Corrosion resistant stainless steel shell and tube air/water and oil coolers
  • Air/Water coolers feature integrated moisture separators
  • Coolers are ASME coded standard

STARTER/DRIVE

  • Fixed Speed/Wye-Delta Standard
  • UL design
  • Optional integrated VSD
  • IP54 protection for fixed speed
  • IP42 protection for VSD

SILENCER

  • Eliminates pulsation in the airstream
  • Improved sound attenuation
  • ASME Coded

DISCHARGE CHECK VALVE

  • Prevents reverse air flow in order to protect the compressor from damage
  • Stainless steel components ensure long life and proper operation

AUTOMATED CONDENSATE DRAINS

  • Highest efficiency solution
  • Automated — eliminates programming under changing conditions
  • Robust design for long life

AIR INTAKE

  • Combined pneumatically actuated load/unload air inlet
  • High efficiency air inlet filter
  • Non-corrosive components help ensure long life and durability

AIR END LUBRICATION SYSTEM

  • Sullair AWF® lubricant for wide range of temperature applications
  • Independently operated oil pump
  • Combination of labyrinth and carbon ring seals

VARIABLE SPEED DRIVE (VSD)

  • Excellent energy savings
  • Relief from potential peak demand charges
  • Possible utility company rebates
  • Stable system pressure
  • Consistent product quality
  • Reduced system air leaks
  • Reduced storage requirements
  • Flexibility for future growth
  • Lowest life-cycle cost

60Hz

7507W - 100 hp (75 kW), 448 acfm (12.7 m³/min), 100 psi (7 bar)
7509W 100 hp (75 kW), 447 acfm (12.7 m³/min), 125 psi (9 bar)
9007W - 125 hp (93 kW), 534 acfm (15.1 m³/min), 100 psi (7 bar)
9009W -  125 hp (93 kW), 533 acfm (15.1 m³/min), 125 psi (9 bar)
9011W -  125 hp (93 kW), 446 acfm (12.6 m³/min), 150 psi (10 bar)
11507W - 150 hp (112 kW), 655 acfm (18.5 m³/min), 100 psi (7 bar)
11509W - 150 hp (112 kW), 655 acfm (18.5 m³/min), 125 psi (9 bar)
11511W - 150 hp (112 kW), 532 acfm (15.1 m³/min), 150 psi (10 bar)
15007W - 200 hp (149 kW), 801 acfm (22.7 m³/min), 100 psi (7 bar)
15009W - 200 hp (149 kW), 822 acfm (23.3 m³/min), 125 psi (9 bar)
15011W - 200 hp (149 kW), 654 acfm (18.5 m³/min), 150 psi (10 bar)
19007W - 250 hp (186 kW), 1248 acfm (35.3 m³/min), 100 psi (7 bar)
19009W - 250 hp (186 kW), 1112 acfm (31.5 m³/min), 125 psi (9 bar)
19011W- 250 hp (186 kW), 1017 acfm (28.8 m³/min), 150 psi (10 bar)
22507W - 300 hp (224 kW), 1370 acfm (38.8 m³/min), 100 psi (7 bar)
22509W - 300 hp (224 kW), 1308 acfm (37 m³/min), 125 psi (9 bar)
22511W - 300 hp (224 kW), 1244 acfm (35.2 m³/min), 150 psi (10 bar)
25007W - 350 hp (261 kW), 1654 acfm (46.8 m³/min), 100 psi (7 bar)
25009W - 350 hp (261 kW), 1484 acfm (42 m³/min), 125 psi (9 bar)
25011W - 350 hp (261 kW), 1367 acfm (38.7 m³/min), 150 psi (10 bar)
